No, you should not bypass a water heater thermal switch, because it’s the last overheat cutoff and a forced bypass can turn a simple no-hot-water problem into a tank failure or fire. If it keeps tripping, the real fix is to find the cause and replace the bad part.
The most common mistake is resetting it over and over and hoping the switch stays closed. That usually just hides a thermostat, wiring or element problem, and the next trip costs you another cold shower plus a harder repair.
A thermal switch is there to open the circuit when temperature climbs too far. On an electric water heater, that means the heater stops before the tank, wiring or insulation gets cooked.
Why You Should Never Bypass a Water Heater Thermal Switch
No, bypassing a water heater thermal switch is unsafe and should never be used as a repair. The switch opens the circuit when the tank overheats, so a bypass removes the last automatic cutoff protecting the tank, wiring and everyone near the hot-water outlet.
A thermal switch by-pass means joining or rerouting the wires so the heater keeps running even though its temperature limit has opened. A Bradford White hot water heater limit switch bypass does the same thing: it defeats a safety device rather than fixing the reason it tripped.
Repeated trips usually point to a stuck thermostat, a shorted heating element or loose wiring. Any of those faults can keep adding heat after the tank has reached its set temperature.
120°F
Scald-risk reference at the tap
Water hotter than 120°F can cause scald injuries, and a failed control can let tank temperature rise beyond the normal setting.
A water heater is a closed tank, so extra heat raises both water temperature and pressure. The temperature-and-pressure relief valve is another safeguard, but bypassing the thermal switch can push the tank toward damage before that valve operates; damaged insulation or loose wiring can also create a fire hazard.
In short
Leave the thermal switch in the circuit and find out why it opened. A reset may restore hot water once, but a repeat trip needs testing and the correct replacement part.
Do not bridge the wires
Never tape, jumper or twist around the switch, and never leave a heater operating with its cover removed. Turn off the circuit breaker for an electric unit or the gas supply as directed by the manual, then arrange qualified service if the cause isn’t clear.
Myth
A bypass is acceptable if the heater works normally afterward.
Fact
The heater may run normally right up to the next overheat event. The bypass hides the warning, leaving fire, tank damage and scalding hazards in place.
For the distinction between a thermal cutoff and the other safety parts in a tank, see our guide to the thermal fuse in water heaters.
Why The Thermal Fuse Trips
A water heater thermal fuse or thermal switch trips when heat reaches its safety limit, and the timing of the trip tells you more than the reset button does. On a domestic water heater thermal fuse on cylinder, the part is usually mounted behind an access panel on an electric unit; gas models use different combinations of thermal switches, flame sensors, rollout controls and thermocouples.
What you see
What it can mean
It resets and stays on after one event
Temporary overheating or a control that is beginning to fail
It won’t reset after a one-time cutoff opens
The switch may be damaged, or the heater is still too hot
It trips again immediately after reset
A failed thermostat, shorted element, wiring fault or continuing overheat
Burn marks or melted insulation are visible
Loose or corroded terminals, overheated wiring or a larger electrical fault
Turn power off before inspecting any wiring; the table is a clue, not a bypass procedure.
If you’re asking where is the thermal fuse located on a hot water heater, start with the manufacturer’s access-panel diagram rather than guessing. Electric models commonly place the limit control near the upper thermostat; gas units may put a thermal switch near the burner area or use a different safety assembly altogether.
Common causes include a thermostat stuck closed, a heating element shorted to the tank, sediment insulating an element so it overheats locally, and terminals that are loose or corroded. An incorrect temperature setting can also keep the heater working longer and expose a weak control to repeated high heat.
A fuse that doesn’t reset
A blown non-resettable thermal fuse needs replacement with the specified part. Bypassing it leaves the heater without that cutoff and can turn a small parts failure into a dangerous one.
If the original switch is visibly damaged or fails to reset, first match the heater model and the part number before ordering anything.
If your switch matches the listed models
239-43676-03 & 415-43676-03 Resettable KSD301-290F Water Heater Therm…
Product 1 is a resettable 290°F thermal switch for listed Bradford White part numbers 239-43676-03 and 415-43676-03, with two 1/4-inch quick-connect terminals. It replaces the switch only; it won’t correct a bad thermostat, shorted element or damaged wiring.
Record the heater model and the number printed on the original switch
Look for melted insulation, dark terminals or loose connections with power off
Check whether the switch resets after the heater has cooled
Stop and arrange service if the cause is gas-related, wiring-related or unclear
Check The Heater Before Buying Parts
A safe thermal cutoff for electric water heater replacement repair starts with diagnosis, not a jumper wire or a guessed part. If your water heater thermal switch keeps tripping, the switch may be protecting you from a stuck thermostat, blocked airflow, loose wiring or excess heat.
1
Shut everything down
Turn off the water heater breaker, close the gas control if the unit burns gas, and let the tank cool. Verify the electric circuit is dead before removing any access panel.
2
Inspect before testing
Look for melted insulation, scorched terminals, a loose high-limit switch, blocked air openings and heavy sediment. A loose or discolored switch usually points to heat damage, not a screw you can simply tighten and ignore.
3
Test with power off
A multimeter can check continuity through the thermal switch and thermostat after the wires are isolated as the manufacturer directs. An open switch may be normal while hot, but a switch that stays open after cooling—or a thermostat that doesn’t open at its set temperature—needs the correct repair.
4
Flush heavy sediment
If the tank has substantial sediment, follow the manual’s drain and flush procedure after the water cools. Sediment can insulate the heating area, reduce heat transfer and contribute to overheating.
Worked Example
Say an electric heater repeatedly trips its upper limit after a short heating cycle. The upper thermostat is stuck closed, so the top of the tank keeps receiving heat after it should stop; the thermal switch trips as the temperature rises. Replacing only the switch leaves that thermostat fault in place.
SymptomUpper limit trips repeatedly
Likely causeThermostat stuck closed
Repair directionTest and replace the failed control
Stop and call a licensed electrician or plumber if the panel shows burned wiring, the breaker trips, gas or venting is involved, or you can’t positively identify the circuit and controls. For a damaged switch on a compatible Bradford White model, a correctly matched replacement can address the part itself, but it won’t cure the condition that made it trip.
For compatible Bradford White models
239-43676-03 & 415-43676-03 Resettable KSD301-290F Water Heater Therm…
Product 1 is a 290°F resettable switch listed for specific Bradford White part numbers and series, including MI-T6FBN and 50T65F models. Match the original part and wiring first; it isn’t a universal replacement.
Don’t check continuity on an energized water heater, bypass the limit, or keep resetting a switch that trips again. Repeated trips are a fault signal.
From HeaterGuides · our own guidePages 9 to 13 are the fault flowcharts: no hot water, noises, smells and leaks, in order.Water Heater Owner's ToolkitFix the common faults yourself, keep it running for years, and know when a repair is money wasted.No-hot-water flowcharts, gas and electricFlush, anode, relief valve and descaling stepsRepair-or-replace calculator (Excel)$14.99$9.99Get it for $9.99See what's inside and watch the 2-minute video →18-page printable PDF + Excel calculator · instant download · 30-day refund
Replace The Failed Switch The Right Way
Replace a failed thermal switch with the exact compatible part after testing shows the switch is defective; don’t use a generic thermal fuse or one from a portable water heater. A safety cutoff must match the heater’s design, temperature rating, terminals and mounting.
For a Bradford White unit, read the old part number and model label before ordering, then compare the replacement’s terminal layout and mounting ears. Product 1 is an example for specified Bradford White models, not a universal part for every gas or electric heater.
If your model matches the listed Bradfor
239-43676-03 & 415-43676-03 Resettable KSD301-290F Water Heater Therm…
Product 1 is intended for Bradford White part numbers 239-43676-03 and 415-43676-03 and uses two 1/4-inch quick-connect terminals. It includes the switch only, so it doesn’t replace a thermocouple, ignitor or pilot assembly.
An expansion tank handles pressure created when heated water expands in a closed plumbing system; it does not fix an overheating thermal switch. Installing one means connecting it to the cold-water line at the point specified by the heater or plumbing layout, setting its air charge correctly and checking for leaks, so a licensed plumber should handle the work where required.
Correct repair
Matches the heater’s listed part and temperature rating
Keeps the overheat protection working
Addresses the failed component after the cause is checked
Unsafe shortcut
A wrong part can trip early or fail to protect
Gas and electrical work may require a licensed professional
Gas connections, venting, 240-volt wiring and T&P valve work belong to licensed professionals where local rules require it. Never cap or plug the T&P discharge line, and don’t connect an expansion tank to the thermal-switch circuit; it belongs in the plumbing system, not the safety-control wiring.
What To Do Instead Of Bypassing It
If the thermal switch trips again immediately, shut off power at the breaker and leave the heater off until the fault is found. A leak at an electric water heater connection can involve thermal-expansion pressure or a loose plumbing fitting, so shut off the water supply too if water is escaping.
Safe Next Steps
Look for burned terminals, melted insulation, loose wires, or discoloration around the thermostat and element.
Replace a failed thermostat or heating element with the correct compatible part.
Flush sediment from the tank if the manufacturer’s procedure allows it; buildup can reduce heat transfer and contribute to overheating.
If the plumbing system is closed, verify that a working, correctly sized expansion tank is installed.
A thermal water heater expansion tank is a plumbing pressure-control device, not a substitute for the cutoff. Installing one means connecting a potable-water-rated tank on the cold-water line, setting its air charge to match the home’s water pressure with the tank isolated, and checking for leaks; a licensed plumber should handle the work where local rules require it. DIY installation is only sensible if you can identify the cold-water line, follow the tank instructions, and meet local code.
Leave The Safety Controls Alone
Never cap, jumper, tape over, or otherwise defeat a thermal cutoff or the temperature-and-pressure relief valve. Never cap the T&P discharge line either. A working carbon monoxide alarm also matters if a fuel-burning appliance is nearby, but it doesn’t make an electric water-heater repair safe.
In short
A repeat trip means the heater needs diagnosis, not a bypass. Keep the breaker off and call a licensed plumber or electrician when the fault involves 240-volt wiring, a leaking tank, gas equipment, or uncertain testing.
More Questions, Answered
Can you bypass a water heater thermal fuse?
No. A jumper removes the cutoff that limits dangerous overheating, so leave the heater off and find the cause instead. Replace the fuse only with the manufacturer-specified part after power is disconnected.
Where is the thermal fuse located on a hot water heater?
Location depends on the heater design: electric models may place the thermal cutoff near the upper thermostat, while gas models may use a switch near the combustion or flue area. Use the unit’s parts diagram, and shut off gas or power before opening any access panel.
Why does my water heater thermal switch keep tripping?
Repeated trips can point to excessive heat, a blocked flue or venting problem, a failed thermostat, restricted airflow, or a weak switch. A gas heater needs prompt inspection because poor venting can also raise carbon-monoxide risk.
How do I know if I need a Bradford White thermal switch?
Match the replacement to the heater’s model and serial information, not just the brand name or the switch’s appearance. Bradford White units can use model-specific safety parts, so confirm the exact part in the manufacturer’s parts information or with a qualified technician.
Do I need an expansion tank if my water heater trips?
Usually no: an expansion tank manages pressure from heated water in a closed plumbing system, while a thermal switch responds to excessive temperature. Pressure problems can still damage plumbing, so have a technician check the system if the relief valve drips or pressure rises.
Should I replace the thermal switch or the thermostat first?
Test the thermostat, wiring and thermal switch before replacing either part. A thermostat that fails closed can cause overheating, while a switch that opens at the wrong temperature can trip by itself; replacing parts at random can leave the real fault in place.
