Does Low Point Drain Empty Water Heater Completely?

A low point drain can help empty a water heater by allowing sediment and water to flow out, but it may not fully empty the tank without additional steps.

Low point drains help remove water from RV plumbing systems, but their effectiveness for draining water heaters depends on your setup. While they can assist in draining, they may not remove all water from the tank.

Low point drain on water heater releasing water

How Low Point Drains Work

Low point drains are valves installed at the lowest points in your RV’s plumbing system. They serve two primary purposes:

  • Draining water from pipes during winterization
  • Relieving system pressure when switching water sources

These drains typically come in pairs – one for hot water lines and one for cold water lines. When opened, they allow water to drain from the connected pipes by gravity.

Connection to Water Heaters

The hot water low point drain connects to the outlet side of your water heater. This means:

  • It can drain water from the heater’s outlet pipe
  • It may partially drain the tank itself if positioned correctly
  • Complete drainage usually requires opening the tank’s drain plug
Low point drain empties water heater effectively

Effectiveness for Water Heater Drainage

Whether low point drains can fully empty your water heater depends on several factors:

Factor Impact on Drainage
Drain position Must be below tank outlet to work
Tank design Some models drain better than others
Water pressure Opening faucets helps create vacuum

According to RV owners on MyGrandRV forums, some report complete drainage while others find significant water remains in the tank.

Limitations of Low Point Drains

These drains have several limitations for water heater emptying:

  • Sediment buildup remains in the tank
  • Some models leave 1-2 gallons of water
  • May not reach the tank’s lowest point
READ MORE  Where Is The Ball Valve On A Water Heater? (Quick Guide)

Proper Water Heater Drainage Procedure

For complete drainage and maintenance, follow these steps:

  1. Turn off water heater power (gas/electric)
  2. Allow water to cool below 100°F
  3. Open pressure relief valve
  4. Open hot water faucets inside RV
  5. Remove anode rod or drain plug
  6. Flush tank until water runs clear

For Suburban water heaters, consider installing an access door for easier maintenance.

When Low Point Drains Help

Low point drains can assist in these situations:

  • Quick partial drainage between trips
  • Relieving system pressure before maintenance
  • Initial water removal before full drain

Winterization Considerations

During winterization, low point drains serve an important role:

  • They remove most water from pipes
  • Help prevent freeze damage to plumbing
  • May reduce antifreeze needed

However, as noted on R-Pod forums, you should still use compressed air or antifreeze for complete protection.

Alternative Drainage Methods

For more effective water heater drainage, consider:

  • Installing a check valve for easier draining
  • Using a water heater flush kit
  • Adding a secondary drain valve

Manufacturer Recommendations

Most water heater manufacturers recommend:

  • Annual complete draining for maintenance
  • Using the designated drain plug
  • Flushing to remove sediment

While low point drains can help, they shouldn’t replace proper tank draining procedures.
