How to Install a Titan Water Heater: Step-by-Step Guide

To install a Titan water heater, first turn off power and water, then connect the water lines and electrical wiring according to the manufacturer’s instructions.

Installing a Titan tankless water heater requires careful attention to plumbing and electrical connections. This guide covers everything from mounting to final testing, ensuring a safe and efficient installation.

Step-by-step guide for installing a water heater

Tools and Materials Needed

Before starting, gather these essential items:

  • 7/8″ wrench
  • Drill with appropriate bits
  • Level
  • Pipe cutter
  • 6AWG or 8AWG copper wire (depending on model)
  • 1/2″ or 3/4″ copper/CPVC pipes
  • Shut-off valves
  • Sediment filter
  • Pressure relief valve
Mount water heater installation guide steps

Mounting the Water Heater

Choosing the Location

Select a spot near your main water lines and electrical panel. The Titan SCR-2 series requires vertical mounting with screws spaced 6 1/2 inches apart.

Installation Steps

  1. Mark screw locations on wall using the unit as a template
  2. Drill pilot holes
  3. Secure unit with provided screws
  4. Use a level to ensure proper alignment

Plumbing Connections

Pipe Requirements

Titan heaters work with 1/2″ or 3/4″ copper or CPVC pipes. The best tools for HVAC technicians include pipe cutters that ensure clean connections.

Connection Process

  1. Install shut-off valves on both inlet and outlet
  2. Connect cold water inlet (marked blue)
  3. Connect hot water outlet (marked red)
  4. Add sediment filter on inlet side
  5. Install pressure relief valve

Important: Never use Teflon tape on connections. Tighten nuts with a 7/8″ wrench to avoid damage.

Electrical Wiring

Wire Specifications

SCR-2 series models require:

Model Wire Size Breaker Size
Titan N-120 6AWG 60A
Titan N-85 6AWG 50A

Wiring Steps

  1. Turn off main power
  2. Run appropriate gauge wire from panel to unit
  3. Connect ground wire to breaker panel
  4. Install proper breaker (match unit requirements)
  5. Consider adding a disconnect box near unit
READ MORE  How to Drain Your AO Smith Water Heater in 7 Simple Steps

According to USA Tankless, improper wiring is the most common installation error.

Initial Startup and Testing

Water Flow Check

  1. Open cold water supply valve
  2. Open hot water faucet nearest unit
  3. Let water run for 20 seconds to purge air
  4. Check all connections for leaks

Power Activation

  1. Ensure unit has water flow
  2. Turn on power at breaker
  3. Set desired temperature (105-120°F recommended)
  4. Test multiple faucets to confirm operation

Maintenance Tips

Regular maintenance extends your Titan’s lifespan:

  • Clean sediment filter monthly
  • Check pressure relief valve annually
  • Inspect wiring connections yearly
  • Consider HVAC coil cleaner for mineral buildup

Troubleshooting Common Issues

No Hot Water

Check power supply, water flow, and reset button. The Titan’s digital microprocessor samples temperature 21 times per second for consistent performance.

Fluctuating Temperatures

Adjust flow rate or power mode. As noted on Tankless Water Heater, medium flow (1 GPM) provides optimal temperature control.

Safety Considerations

  • Never weld pipes near installed unit
  • Avoid excessive solder paste
  • Don’t open unit casing (voids warranty)
  • Install drip pans if required by code

The Titan’s 10-year warranty on water-carrying components makes it a reliable choice when properly installed.
